Semi-Automatic Mechanical Bench Gap Bed Engine GH1440K Lathe Machine

(14 Lượt)

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

Nhà sản xuất, chế tạo • 2 năm

Semi-Automatic Mechanical Bench Gap Bed Engine GH1440K Lathe Machine

Liên hệ nhà cung cấp Chat now

Những điểm chính về sản phẩm

Thuộc tính cụ thể của ngành

Các thuộc tính khác

Khu vực

Thương hiệu

Mã sản phẩm

Tên sản phẩm

Semi-Automatic Mechanical Bench Gap Bed Engine GH1440K Lathe Machine

Nhà cung cấp

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

Thông tin nha cung cấp của bạn

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

2 yrs

Vị trí tại VN

Thời gian đáp ứng

≤2h

Tỷ lệ giao hàng đúng hẹn

95%

Sản phẩm Cửa hàng

Mô tả sản phẩm từ nhà cung cấp

Mô tả sản phẩm

Product Description

Enging and lathe machine C6236:

Standard accessories:

3 jaw chuck, 4 jaw chuck,steady rest,follow

rest,face plate,coolant pump,work light,chang

gears,dial indicator,dead center and center

sleeve,splash guard,chip pan,toolbox with

tools.

Optional accessories:

CE chuck guard with micro

switch,celeadscrew cover,toolpost guard,taper

turning attachment,digital read out,right

handwheel is alternative.

Specification

MODEL					GH-1440K(CQ6236)
GENERAL CAPACITY	MAX.SWING OVER BED	MM	356(14")
		MAX.SWING OVER CARRIAGE	MM	210(8-1/5")
		MAX.SWING OVER GAP	MM	508(20")
		WIDTH OF BED	MM	260(10-1/5")
		DISTANCE BETWEEN CENTERS(TWO CENTERS)	MM	750(30")/1000(40")
MAIN SPINDLE	TAPER OF SPINDLE BORE		MT-5
		DIAMETER OF SPINDLE BORE	MM	40(1-1/2")
		NUMBER OF SPINDLE SPEEDS		12
		RANGE OF SPINDLE SPEEDS	RPM	40-1800
		SPINDLE NOSE		D4
THREADING & FEEDING	METRIC THREADS		37KINDS/(0.4-7MM)
	METRIC THREADS				23KINDS/(0.45-7.5MM)
		WHIT-WORTH THREADS		28KINDS/(4-56T.P.L')
		WHIT-WORTH THREADS			40KINDS/(4-112T.P.I")
		RANGE OF LONGITUDINAL FEEDS	MM/R	0.043-0.653(0.0012"-0.0294")
		RANGE OF CROSS FEEDS	MM/R	0.024-0.359(0.0004"-0.0103")
LEADSCREW	DIAMETER OF LEADSCREW	MM	22(7/8")
LEADSCREW		PITCH THREADS OF LEADSCREW		4MM OR 8T.P.I
TAILSTOCK	TRAVEL OF TAILSTOCK QUILL	MM	120(4-3/4")
TAILSTOCK		TAPER HOLE OF TAILSTOCK QUILL	MM	MT-3
POWER	MAIN MOTOR POWER	KW	2.4KW(3HP),3PH,4P,60HZ,230V
	COOLANT PUMP MOTOR POWER	KW	004KW(0.055HP)
OVERALL DIMEMTIONS OF LATHE(LXWXH)			MM	1900X710X1170
PACKING SIZE OF LATHE(LXWXH)			MM	1900X760X1435
NET WEIGHT			KG	1200(2650LBS)
GROSS WEIGHT			KG	1300(2850LBS)
