Product Description

Drilling machine refers to a machine and

equipment that leaves cylindrical holes or

holes in the object by means of rotary cutting

or rotary extrusion with a harder and sharper

tool than the object. Also known as drilling

machines, drilling machines, drilling machines,

through the hole machine and so on.

Through drilling precision parts to achieve the

desired effect, drilling machine has semi-

automatic drilling machine and automatic

drilling machine, with the increase of human

resource cost; Most enterprises consider

automatic drilling machine as the development direction. With the development of The Times, automatic drilling machine drilling technology to improve, the use of automatic drilling machine for all kinds of metal mold watchband drilling watchband drilling jewelry drilling advantages are obvious.

Specification

odel			ZAY7045 ZAY7045G ZAY7045G	ZAY7040 ZAY7040G ZAY7040FG	ZAY7032 ZAY7032G ZAY7032FG	ZAY7020 ZAY7020G
Drilling capacity			45mm	40mm	32mm	20mm
Face milling capacity			80mm	80mm	63mm	63mm
End milling capacity			32mm	32mm	20mm	14mm,20mm
Distance from spindle nose to table			450mm, 680mm	450mm, 680mm,440mm	450mm, 680mm,440mm	382mm,350mm
Min. distance from spindle axis to column			193.5mm,272.5mm,260mm	193.5mm,272.5mm,260mm	193.5mm,272.5mm,260mm	202mm,175mm
Spindle travel			130mm	130mm	130mm	120mm,130mm
Spindle taper			M.T.4 or R8	M.T.4 or R8	M.T.3 or R8,M.T.4 or R8	M.T.3
Step of spindle			12,6	12,6	12,6	12,6
Range of spindle speed	50Hz	80-2080,80-1250r.p.m.	80-2080,80-1250r.p.m.	80-2080,80-1250r.p.m.	80-2080,80-1250r.p.m.
Range of spindle speed		60Hz	100-2500,95-1500r.p.m.	100-2500,95-1500r.p.m.	100-2500,95-1500r.p.m.	100-2500,95-1500r.p.m.
Swing diameter of headstock			405mm,680mm,	405mm,680mm	405mm,680mm	405mm,680mm
Swivel angle of headstock	horizontally	3600	3600	3600	3600
Swivel angle of headstock		perpendicularly	+900	+900	+900	+900
Size of table			800 x 240mm2, 700x 240mm2	800 x 240mm2, 700x 240mm2	800 x 240mm2, 700x 240mm2	585 x 190mm2
Forward and backward travel of table			175mm	175mm	175mm	150mm
Left and right travel of table			500mm, 400mm	500mm, 400mm	500mm, 400mm	380mm
Power			1.5kw (2Hp)	1.1kw (2Hp),1.1kw(0.75Hp)	0.75kw (1Hp)	0.75kw (1Hp),0.55kw (1Hp)
Voltage/Fequency			As custmers requirement	As custmers requirement	As custmers requirement	As custmers requirement
Overall height (Without stand)			1060mm; 1300mm;1020mm	1060mm; 1300mm;1020mm	1060mm; 1300mm;1020mm	1060mm; 1300mm
Net weight			285kg,320kg,325kg	283kg,318kg,323kg	280kg,315kg,323kg	270kg,300kg
Gross weight			335kg,370kg,375kg	333kg,368kg,373kg	330kg,365kg,370kg	330kg,350kg
			880 x 770 x 1140mm3	880 x 770 x 1140mm3	880 x 770 x 1140mm3	880 x 770 x 1140mm3
Packing size			880 x 832 x 1140mm3	1030 x 770 x 1140mm3	880 x 832 x 1140mm3
			1030 x 832 x 1140mm3	1030 x 832 x 1140mm3	1030 x 832 x 1140mm3
Loading amount (overall height)			36pcs/20container 18pcs/20container 28pcs/20container	36pcs/20container 18pcs/20container 28pcs/20container	36pcs/20container 18pcs/20container 28pcs/20container	36pcs/20container 18pcs/20container
