High-Speed Automatic Hydraulic Double Action Press Machine

(15 Lượt)

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

Nhà sản xuất, chế tạo • 2 năm

Giá

300,000,000 đ

Giá sỉ

0986258282

Giá số lượng lớn

0986258282

High-Speed Automatic Hydraulic Double Action Press Machine

Liên hệ nhà cung cấp Chat now

Những điểm chính về sản phẩm

Thuộc tính cụ thể của ngành

Các thuộc tính khác

Khu vực

Thương hiệu

Mã sản phẩm

Tên sản phẩm

High-Speed Automatic Hydraulic Double Action Press Machine

Nhà cung cấp

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

Thông tin nha cung cấp của bạn

THIẾT BỊ CƠ KHÍ LUOHE GOLDEN SHELL

2 yrs

Vị trí tại VN

Thời gian đáp ứng

≤2h

Tỷ lệ giao hàng đúng hẹn

95%

Sản phẩm Cửa hàng

Mô tả sản phẩm từ nhà cung cấp

Mô tả sản phẩm

Product Description

Purposes and Features of Hydraulic Press:
This machine is used to suppress technology for materials with plasticity.This machine has independent actuating unit and electric system, as well as adopts centralized control with button, which can realize two kinds of operating modes of inching and semi-automatic.Working pressure and scope of stroke of this machine should be adjusted according to the technology.

Specification

ltem	YAN27-63
Nominal Force	630	KN
Return Force	180	KN
Cushion Force	200	KN
Max. pressure of liquid	25	MPA
Stroke Slide	450	mm
Stroke Cushion	180	mm
Max. Daylight	900	mm
Slide speed Descent	120	mm/s
Slide speed Pressing	11月15日	mm/s
Slide speed Return	130	mm/s
Table Dimensions L-R	560	mm
Table Dimensions F-B	500	mm
Cushion Dimensions L-R	310	mm
Cushion Dimensions F-B	300	mm
Height of table above Floor	750	mm
Total Power	11	kw
Total Weight	4200	kg

Company Profile

Our Service

Overseas after sales service outlets
TOPTECH SMAC MACHINERY LIMITED（Canada）
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office:905 238 8912
Contact: Mrs Merry NA

COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat

SJR MACHINERY LIMITED（Algeria）
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed
mobile number 0542 695 457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807
Email:Mezouarstar@gmail.com

Packing & Delivery

We choose the best packaging, the most excellent
logistics services, to ensure that your goods faster and safer to reach the destination.

FAQ

Q.What are your normal lead times?
A.Our company typical lead times range from 3-4weeks after receipt of order.

Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.

Q.What kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.

Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.

Q.Do you have CE certification
A.Yes, we have CE certification, machine quality is one year guaranteed.

Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to
provide customers better quality, better price, and better service".

High-Speed Automatic Hydraulic Double Action Press Machine

Giá

300,000,000 đ
